Specifications – Keysight DSOS804A
| Specification | Value |
|---|---|
| Bandwidth | 8 GHz |
| Channels | 4 analog channels |
| Sample rate | 20 GSa/s max |
| Memory depth | 100 Mpts/channel standard |
| ADC resolution | 10-bit (up to 16-bit enhanced resolution) |
| Display | 15-inch XGA capacitive touchscreen |
Note: The specifications above are for reference only. Please refer to the official datasheet for exact information.
Highlights
- Superior signal integrity with a system ENOB of 8.1 bits at full bandwidth
- Enhanced resolution mode achieves up to 16 bits of vertical resolution
- 15-inch multi-touch capacitive touchscreen with solid-state drive for increased usability
- 100 Mpts/channel of standard acquisition memory at 20 GSa/s max sample rate
This Keysight DSOS804A is a genuine, factory-calibrated unit distributed by AMPELAB, offering reliable bench-level performance for training, repair, and production QA applications.
What’s included:
- Four N2873A 500 MHz passive probes
- Probe accessory pouch
- 8 GHz BNC calibration cable
- Keysight I/O libraries suite
- Keyboard and mouse
Applications – Keysight DSOS804A
The Keysight DSOS804A is well suited for high-speed serial link characterization, advanced signal integrity and jitter analysis, and top-tier R&D and compliance validation tasks.
Explore our full range of oscilloscopes for other bandwidth and channel options.
